RMF-5KP2K Photo Sensor

• Standard M18 cylindrical metal tube.
• Threaded length = 35 mm.
• ABS barrel applied to factory environments.

Description

Specification
Model Tubular Photo Sensor
Sensing distance Through beam
Detection distance 5M
Light Emitter Infrared LED 850 nm
Operating voltage DC12 ~ 24 V
Current consumption 45 mA Max.
Load current 100mA Max. at DC24V
Model / Type NPN L.on / D.on PNP D.on / L.on
Response time 650 Hz
Insulation resistance 20MΩ min. (DC500V)
Voltage withstandability AC1000V 60Hz for 60 Sec.
Opera tetemperature -25℃ ~ + 60℃
Operating temperature 35% ~ 85% RH
Protection degree IP66
Casing material ABS
Wiring method M12 pigtailed type
Option M124R-PVC-2M / Bracket : MF-01
Weight 60g
