ASC0802-N3 Tubular Inductive Proximity Sensor
• SUS304
• The IP67K rating is designed to the effective waterproof.
• N3 / P3 model : NPN N.O. / N.C. & PNP N.O. / N.C. 2-in-1 outputs.
• Surge suppressor and overload protection.
Description
Specification
| Model | Tubular Inductive Proximity Sensor |
|---|---|
| Detection distance | 2 mm ± 10% |
| Standard sensing object | Iron 8 x 8 x 1 mm |
| Sensing distance | Unshielded |
| Description | Standard M8 |
| Hysteresis | ≦ 15 % of sensing distance |
| Response time | 500 Hz |
| Operating voltage | DC 12 ~ 30 V |
| Current consumption | ≦ 8 mA no-load |
| Load current | 100 mA Max. at DC 24V |
| Residual voltage | ≦ DC 2V |
| Insulation resistance | 20MΩ min. (DC500V) |
| Voltage withstandability | AC 1000 V 60Hz for 60 Sec. |
| Opera tetemperature | -20℃ ~ + 60℃ |
| Protection degree | IP 67K |
| Option | M84R-2M-PVC / M84RL-2M PVC |
| Wiring method | Ø3 x 2M / 3 wires |
