SPR401-P Micro Photo Sensor
• Front surface / Top surface sensing models
available.
• Light ON/Dark ON selectable.
Description
Specification
| Model | Micro Photo Sensor |
|---|---|
| Sensing distance | Diffuse Reflection |
| Detection distance | 40 mm ( 10x10cm White paper ) 8 mm ( 10x10cm Black non-glossy paper ) |
| Light Emitter | Infrared LED 940nm |
| Detection direction | Top surface |
| Operating voltage | DC12 ~ 24 V |
| Current consumption | 25 mA Max. |
| Load current | 100 mA Max. at DC24V |
| Model / Type | PNP L.on/ D.on |
| Response time | 1000 Hz |
| Ambient illumination | 受光面照度: 6,000 lux max. |
| Insulation resistance | 20MΩ min. (DC500V) |
| Voltage withstandability | AC 1000V 60HZ for 60 Sec. |
| Opera tetemperature | - 20 ℃ ~ + 45 ℃ (No freezing allowed ) |
| Operating temperature | 35% ~ 85% RH |
| Casing material | PC |
| Protection degree | IP 50 |
| Option | RE-1103-PVC-1M (1M/2M/3M/5M) |
| Weight | 3g |
