SIR15-KP2 Proximity Sensor
• Suitable for the detection of tiny metal passing.
• The pigtailed type connector makes easy disconnection.
• 12-turn sensitivity adjuster. Users can adjust the sensitivity more optimum according to different objects.
• Daul LED makes you easy to know the current operating situation.
Description
Specification
| Model | Ring Inductive Proximity Sensor |
|---|---|
| Sensing hole diameter | D = 15mm |
| Minimum detectable object | 2 mm min. |
| Operating voltage | DC 12 ~ 24V |
| Current consumption | 25 mA |
| Load current | 100 mA Max. at DC 24V |
| Model / Type | NPN N.O / N.C. , PNP N.C. / N.O. |
| Opera tetemperature | -20℃ ~ + 60℃ |
| Protection degree | IP 66 |
| Option | M124R-PVC-2M |
| Wiring method | Ø5.2 X 2M / 4-wires |
| Weight | 86g |
