PRC-620-L35 Lens Built in Fiber Sensor
• Fiber Type：Lens Built in Fiber Optics Sensor
• Light spot : 3.5 mm from the 30 mm
Description
Check if the screw has a chamfer.
At a height of 3cm, the Ø3.5mm light spot is suitable for inspecting nuts (10x10mm) for chamfering on a vibratory feeder and for inspecting small objects under normal circumstances.
Specification
| Fiber diameter | OD=Ø2.2,ID=Ø0.OD=Ø2.2 ; ID=Ø0.5x1 / Ø0.269x95 |
|---|---|
| SD | 35mm |
| Opera tetemperature | -55℃~+70℃ |
| Mini.bending radius | R25 |
| Light spot | 3.5 mm from the 30 mm |
