AN08-P31 Close-range rectangular proximity sensor
•Compact size (34mm x 18mm x 18mm) .
•Features a rectangular hole for easy and precise installation adjustments .
•Items with different frequencies.
•N3/P3 model : NPN N.O./N.C. & PNP N.O./N.C. 2-in-1 outputs.
Description
Specification
| Model | Close-range rectangular proximity sensor |
|---|---|
| Model / Type | PNP N.O. / N.C. |
| Oscillation frequency differentiation | Different frequencies |
| Detection distance | 8mm |
| Secure sensing distance | 0~6.4 mm |
| Standard sensing object | Iron |
| Sensing distance | Front surface |
| Hysteresis | ≦10 % of sensing distance |
| Response time | 500 Hz |
| Operating voltage | DC 12 ~ 30V |
| Current consumption | 12 mA max / ≦ 9 mA no-load |
| Insulation resistance | 20M Ω min. (DC500V) |
| Voltage withstandability | AC1000V 60Hz for 60 Sec. / DC 90V (0.1s) |
| Opera tetemperature | -20℃ ~ + 60℃ |
| Protection degree | IP 67 |
| Option | |
| Wiring method | Ø4.2 x 2M / 3 wires |
| Weight | 60g |
